Product Training
Product Training
This is an invitation to technical training in both
AQ 100 and AQ 200 series devices.
The training is open to all partners and end-users.
The training will be arranged in Arcteq AQademy in Vaasa as on-site training only, and it is free of charge.
Training in Vaasa:
21. - 24.11.2022
(please scroll down for the day-specific training content)
Enroll by clicking the orange "Register" button in the upper right corner.
Last enrollment day is 13.11.2022
Hope to see you in Vaasa!
Accommodation and transport
Accommodation
You can choose your own accommodation, or we can book you a hotel room at hotel Astor.
Just choose the option that suits you best on the registration form, and we will act accordingly.
Our partner, Hotel Astor is located in the center of Vaasa, just across the street from the railway station: https://astorvaasa.fi/?page=HOME&setlang=l3
Room rates:
Single room: 107€
Double room: 127€
Breakfast is included in the room rates.
Transport
Arcteq arranges a minibus transport all mornings & afternoons from hotel Astor to Arcteq, and back.
The taxi departures every morning from Hotel Astor at 08:45 (EET).
Transport from Vaasa Airport (upon arrival)
If you want us to book a taxi transport from the airport, please contact
minna.holmberg@arcteq.fi and remember to include your flight details to your request.
Evening program
We have arranged for evening program on Tuesday. The program starts directly after the day program at 16:00 and will end approximately at 22:00.
Finnish sauna, swimming in the ice hole*, and archipelago dinner will be no strangers to you after this evening. The towels are provided for.
* weather reservation, a warm water jacuzzi is also available for those who prefer warmer water temperatures.
Product Training Content
Monday
21.11.2022
9:00 - 16:00 (EET)
_______________________
Arcteq Company presentation
Arc Fault
Arc Flash phenomena
Typical Arc Protection applications
AQ 100 product presentation
AQ 100 arc protection
AQ 100 installation and configuration SAS applications
AST-02 test equipment
AQ-1000 Arc Quenching devices
AQ-100 LV AQD Product installation and configuration
SiQuench 24kV AQD part of Arcteq Arc Flash System
Tuesday
22.11.2022
9:00 - 16:00 (EET)
______________________________
AQ 200 and AQ 300 product overviews
AQtivate 200 setting tool training
General info
Hardware setup
Protection (geneneral)
Communication (general)
Fault register and fault recorder
Mimic
Logic tool
AQtivate 200 setting tool training
(continue)
The evening program begins right after the training at 16:00.
Wednesday 23.11.2022
9:00 - 16:00 (EET)
_____________________
AQ 21x/25x configuration training
Independent tasks according to instructions
AQ 21x/25x configuration training (continue)
Motor thermal Wizard
New functionality in AQtivate 200
Transformer differential protection wizard
A wizard for determining differential settings from rating values
New features and products in AQ 250 series
AQ-C255 Capacitor bank protection relay
AQ-F255R Feeder protection relay
AQ-V251 Voltage protection relay
AQ-F255V Transformer protection relay
Thursday 24.11.2022
9:00 - 15:30 (EET)
______________________
Communication protocols
Modbus and the configuration of modbus map
Fast modbus in AQ-P215
Modbus Gateway
IEC101/104
IEC103
DNP3
Communication protocols
IEC 61850, Training with
new AQtivate tool ed. 1 and e. 2
Time synchronization
NTP
PTP
IRIG-B
Redundancy protocols
HSR
PRP
